15m power driven telescoping towers for video cameras

FOB Reference Price:Get Latest Price
  • 1 - 4 Sets
    US$2,250.20
  • 5 - 9 Sets
    US$2,203.60
  • 10 - 19 Sets
    US$2,168.10
  • >=20 Sets
    US$2,100.56
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Tianjin, China (Mainland)
Brand Name:
Talents. 15m power driven telescoping towers for video cameras
Model Number:
TAL-E15-2.8-30-A
Product name:
15m power driven telescoping towers for video cameras
Extended height:
15m(50FT)
Closed height:
2.8m(9.2FT)
Material:
Aluminum Alloy
Type:
Motorized lifting
Motor Voltage:
AC220v/300w
Max payload:
30kg
Max windload:
80km/h
Color:
Army green
Application:
antenna, camera,light tower
Supply Ability
Supply Ability:
1000 Set/Sets per Month 15m power driven telescoping towers for video cameras
Packaging & Delivery
Packaging Details
motorized lifting telescopic mast and the accessories are wrapped with foamed membrane and then to be packed into a polywood case
Port
Port of Tianjin China
Lead Time :
15-25days after receiving the payment
Product Description
15m power driven telescoping towers for video cameras

The 33FT Motorized telescopic mast is one of the most popular masts. The extended heights go from 2m up to 10m. This mast model can carry heavier top loads 50kg. It is also available with 8 sections and can be used for the most common uses, like lighting, cameras and telecommunication equipment. The masts can be equipped with a tilt and turn unit.

Specification
15m power driven telescoping towers for video cameras
Model No.
TAL-E15-2.8-30-A
Max top payload:
30kgs
Closed length:
2.8m
Extended length:
15m
Main mast sections
7 sections
tube size:
sec.No. OD*wall thickness
1# 130*5.0mm
2# 105*2.5mm
3# 90*2.0mm
4# 80*2.0mm
5# 70*2.0mm
6# 60*2.0mm
7# 50*2.0mm
TOP flange size(diameter/thickness):
160mm/6mm, With 4pcs*10mm holes
Bottom Flange size(diameter/thickness):
190mm/10mm, with4pcs*10mm holes
Working temperature:
-40--+50C
Motor power:
AC220V/300W
Max Wind load:
80km/h
Accessories
1.220v /DC 12Vmotor---------------------------1pc
2.Control box----------------------------------------1pc
3.Handle lifting bar--------------------------------1pc
4.Remote controller-------------------------------2pcs
5.Bottom flange(base)---------------------------1pc
6.TOP flange------------------------------------------1pc
7.Pulling cord box----------------------------------4pcs
8.Ground anchor------------------------------------4pcs
9.tripod--------------------------------------------------1pc
Detailed Images

Mast body.

Common color is army green or silver color.

But it can be changed to any color as customers' request.

Portable model.

With tripod, more portable for using.

if need vehicle mounted model, we can

give you car clamps for fixing.

Accessories.

Pulling cord box with three layers steel pulling wire, remote controler, flange,

ground anchor...

Packing & Delivery

Plywood case.

Inner packge is EPE to protect all part, plywood case is fittable

for express post, sea shipment and air shipment.
Package information

Gross weight is around 120kg,( with the package weight)

Meas.: 215*45*50cm

Otehr specification
Motorized telescopic mast
Model No.
Retracted height
(m)
Extended
Height
(m)
Diameter range
(mm)
Section
NO.
Head-load
(KG)
TAL-2M-30
1
2
40mm~60mm
3
30
TAL-2M-30
0.75
2
40mm~90mm
6
20
TAL-2M-100
1..2
2
105mm~130mm
2
100
TAL-3M-250
1.75
3
90mm~130mm
3
250
TAL-4M-250
1.8
4
90mm~130mm
3
250
TAL-4M-10
1.55
4
40mm~80mm
4
10
TAL-4M-50
1.2
4
60mm~130mm
6
50
TAL-5M-150
1.4
5
60mm~160mm
6
150
TAL-5M-600
1.6
5
60mm~150mm
5
600
TAL-6M-10
1.7
6
40mm~90mm
6
10
TAL-6M-50
1.7
6
50mm~105mm
6
50
TAL-8M-30
2.2
8
40mm~105mm
6
30
TAL-10M-30
2.45
10
40mm~105mm
7
30
TAL-12M-200
2.45
12
70mm~160mm
7
200
TAL-12M-35
2.3
12
40mm~130mm
7
35
TAL-12M-100
2.7
12
50mm~130mm
7
100
TAL-12M-20
2.4
12
40mm~150mm
7
20
Our Service

Warranty period

Except the damages due to misuse, unauthorized modification and man-made sabotage, the damaged parts will enjoyed free after-sales maintenance within one year's time from the date of delivery on the condition that the buyer himself will bear the shipping cost back and forth and the said damage should be confirmed by the seller through photos and description.

Our Company

Talents enterprise co.,ltd.

Design and supply for all kinds of telescopic mast since 1995Our product range is extremely wide and the applications of our telescopic masts are various: from the most well-known fire-fighting sector to the emergent sector of wind power, but also photography, telecommunication and broadcasting as well as the military sector and many others.
