15m portable military antenna wind telescopic winch mast

FOB Reference Price:Get Latest Price
US$800.00 - US$1,500.00 / Units | 1 Unit/Units (Min. Order)
Lead Time:
Quantity(Units) 1 - 1 2 - 10 11 - 20 >20
Est. Time(days) 7 12 18 Negotiable
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Tianjin, China (Mainland)
Brand Name:
Talents
Model Number:
TAL-M15-2.45-30
total length:
15m
retracted length:
2.45m
No. of section:
8
outer diameter:
bottom 105mm to top 30mm
color:
military green or custom-made color
max.payload:
no less than 30 kg or custom-made
material:
aluminum alloy
lifting method:
manual or electric
installed on:
ground or vehicle
acessories:
tripod or clamp,guy wire,ground anchor etc.
Supply Ability
Supply Ability:
200 Unit/Units per Month military mast antenna
Packaging & Delivery
Packaging Details
package: one set put into a plywood case
Port
China main port
Lead Time :
Quantity(Units) 1 - 1 2 - 10 11 - 20 >20
Est. Time(days) 7 12 18 To be negotiated
Video Description
Product Description
15m portable military antenna wind telescopic winch mast
technical data
main spec.
Closed length:2.45m         (Bottom base included)
Extended length: 15m                  (Bottom base included)
Self weight:around 33kg  Max loading:20kg or customized
Temperature: working temp:-40--+50C Storage Temp:-55--+70C
main pole in sections
Section No.           OD                            Thickness                  Length
1#:                        30mm                     2.0mm                         2.2m
2#:                        40mm                      2.0mm                        2.2m
3#:                        50mm                      2.0mm                        2.2m
4#:                        60mm                      2.0mm                        2.2m
5#:                        70mm                      2.0mm                        2.2m
6#:                        80mm                       2.0mm                        2.2m
7#:                        90mm                       2.0mm                        2.2m
8#                            105mm                     2.5mm                        2.2m

Bottom base
diameter: 180mm                   Thickness: 12mm
Accessories
Pulling cord box with handle bars------------------3 units
Ground anchor------------------------------------------3 pieces
Handle lifting bar---------------------------------------2 pieces
304 stainless steel stakes-------------------------------6 pieces
Tripod -----------------------------------------------------1 piece
Top plate---------------------------------------------------1 piece
Material
Main Pole: aluminum alloy
Bottom base and accessories(except the stakes): iron steel
Pulling cord: stainless steel wire(OD:2mm)
Color
the whole unit will be in army green when closed, but when extended, the main pole will be in origin color of aluminum alloy only with top 4cm of each pole section in army green color.Technology: painting
accessories

Pulling cord box with handle bars------------------3 units
Ground anchor------------------------------------------3 pieces
Handle lifting bar---------------------------------------2 pieces
304 stainless steel stakes-------------------------------6 pieces
Tripod -----------------------------------------------------1 piece
Top plate---------------------------------------------------1 piece

Detailed Images
15m portable military antenna wind telescopic winch mast
Packing & Delivery

15m portable military antenna wind telescopic winch mast

package
carton packed
normal package is carton for the extended height less than 9m, weight less than 70kg mast, also can be plywood case at customers request

plywood packed
normal package is plywood case for extended height more than 10m, weight more than
70kg mast
After-sale service
 Except the damages due to misuse,unauthorized modification and man-made sabotage,
the damaged of the telescopic mast will enjoyed free after-sales maintenance
within one year time from the date of delivery on the condition that the buyer
himself will bear the shipping cost back and forth and the said damage should be
confirmed by the seller through photos and description

Installation Instructions:
1.if mount mast on vehicle,just need car clamps to fix. If mount on ground,fix the base and tripod with stainless steel    stakes,
2.Determine the mounting position of telescopic mast if manual and motorized mast hitting one ground anchor per 120 degrees. If pneumatic mast in 90 degree to fix the Guy rope.
3.Mount lifting handle bar to raise up manual mast. If pneumatic or motorized, use air compressors/foot pump and motor. But if motorized one, hand crank also work.

Maintenance
1.Waterproof and dust proof cover should be put into outdoor storage
2.If there is a situation that is not smooth or obvious noise during lifting mast,add lubricating
 oil to make sure inner Mechanical parts work well. Suggest to add oil to the mast every 2-3 month.
  it's better  mobil 0W-20 oil
3.Regularly check the connection parts in normal condition.
4.Change seals easily on regular time can make mast in good using conditions after
     using 10 thousand times.
Workshop
Our Service
we supply telescopic mast up to 35m,usually used as antenna mast,communication tower,light support,camera mast and so on,custom-made payload to 400kg,customized length,retracted,payload etc. accepted.
catalog of some common grade manual mast as follows-
extended height
(m)
No. of section
retracted height
(m)
outer tube range
(mm)
self weight
(kg)
4
3
1.6
60-80
14
5
4
1.65
50-80
17
6
5
1.7
50-90
21
8
6
1.8
40-90
24
10
7
1.95
30-90
26
12
7
2.2
30-90
28
15
8
2.45
30-105
33
18
9
2.7
30-130
47
20
9
2.95
30-130
55
22
9
3.15
30-130
58
25
10
3.4
30-150
72
30
10
3.85
30-150
84
Welcome to contact

Company profile

About"Talents"
      Talents is a Chinese company that design, manufacture and supply a range of manual/electric/pneumatic/hydraulic operated telescopic masts and lifting devices that made of aluminum alloy tube, stainless steel tube, fiberglass tube and carbon fiber tube.

      Our masts are CE certified, we have been a golden supplier on Alibaba since 2007, we are keeping with our customers an one for one timely information feedback, we have organized an expert team for quality control and inspection system, we have built up Multi-way fast delivery channels and we are supplying one year free after-sale warranty to the buyer.

     We think outside the box and are continually developing new products to meet customer requirements, what you are asking for is our motive power of task, we wish one of our products will well-meet what you demand.

Any questions or inquiry, welcome to contact us at any time

Reply the inquiry by email within 24 hours

                                    by Skype/Whatsapp/Wechat immidately
