20m-30m mobile telescopic manual crank up antenna mast tower for communication ham radio

FOB Reference Price:Get Latest Price
US$1,850.00 - US$2,150.00 / Units | 1 Unit/Units (Min. Order)
Lead Time:
Quantity(Units) 1 - 1 2 - 15 16 - 25 >25
Est. Time(days) 10 18 28 Negotiable
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Tianjin, China
Brand Name:
Talents
Model Number:
TAL-M20-3-15
extended height:
20m
retracted height:
3m
Wind load capacity:
120km/h
Material:
aluminium alloy
color:
black white blue etc
application:
Emergency Lighting, Military, Antenna, Mobile Communication Tower.
outer tube dia.:
30-130mm
max. payload:
15kg
thickness:
2mm to 4mm
working temperature:
-50 deg C to +70 deg C
Supply Ability
Supply Ability:
200 Unit/Units per Month 20 m telescopic antenna mast
Packaging & Delivery
Packaging Details
packing of 20 m telescopic antenna mast: one set put into a plywood case
Port
China main port
Lead Time :
Quantity(Units) 1 - 1 2 - 15 16 - 25 >25
Est. Time(days) 10 18 28 To be negotiated
Video Description
Product Description

20m-30m mobile telescopic manual crank up antenna mast tower for communication ham radio

Telescopic crank mast, light weight, for payload up to 600kg

Telescopic crank masts is characterised by the lightweight construction and in addition
a superior stability, reliability and a long economic lifetime.
The masts are designed for field installation as well as vehicle installation or on a trailer.
Advantages:
1) no power supply needed - easy manual crank up
2)automatic locking collars - locks at any height desired
3) maintenance free
Common applications
our cranks masts are in use for military as well as civil purposes like communication,
monitoring, lighting and measurement techniques.
Essential features

20m-30m mobile telescopic manual crank up antenna mast tower for communication ham radio

Specification
Article number
TAL-M20-3.5-30
Lifting method
manual crank lifting
Closed length and extended length
3.5m to 20m
73material
for main tube: aluminum alloy
net wieght
58kg for mast
Max payload
30kgs
wind load
120km/h
temperature
-50 deg C to +70 deg C
sections
7
outer tube diameter
42mm-132mm
Details

 Accessories.

Usually the pulling rope used on less than 15m mast;The pulling cord box used on above 15m mast;The tripod used in the flat ground;Clamps used in vehicle mounted;The wheels used to help mobile

If you have other accessories requirement, please contact us separately.

Surface treatment .

Painting or Anodizing

Color :

army green, yellow, white, bronze... ...any color OEM is available.

Packing & Delivery

one set of mast and accessories put into a plywood case

Other Specification
Model No.
Extended height(m)
No. Of section
Retracted height(m)
Outer tube range(mm)
Self weight
(kg)
Max.payload
(kg)
TAL-M3-1-20
3
3
1.0
70-90
15
20
TAL-M4-1.5-30
4
3
1.5
50-80
15
30
TAL-M4-1-20
4
3
1.0
70-90
16
20
TAL-M4-1.6-10
4
3
1.6
60-80
14
10
TAL-M5-1.65-10
5
4
1.65
50-80
17
10
TAL-M5-1.2-15
5
5
1.2
40-90
20
15
TAL-M5-1.5-60
5
5
1.5
50-90
20
60
TAL-M5-1.7-100
5
6
1.7
60-130
35
100
TAL-M6-1.7-10
6
5
1.7
50-90
21
10
TAL-M6-1.5-100
6
6
1.5
60-130
40
100
TAL-M6-1.3-60
6
7
1.3
40-130
32
60
TAL-M7-1.8-30
7
7
1.8
40-105
23
30
TAL-M8-1.5-20
8
8
1.5
40-130
34
20
TAL-M9-1.8-40
9
7
1.8
40-105
25
40
TAL-M9-1.8-100
9
7
1.8
60-160
43
100
TAL-M9-1.9-5
9
7
1.9
30-90
25
5
TAL-M10-1.95-10
10
7
1.95
30-90
26
10
TAL-M10-2-40
10
7
2
30-105
31
40
TAL-M12-2.2-10
12
7
2.2
30-90
28
10
TAL-M12-2.1-15
12
7
2.1
30-90
28
15
TAL-M12-2-40
12
8
2.2
40-130
44
40
TAL-M15-2.45-10
15
8
2.45
30-105
33
10
TAL-M15-2.6-35
15
9
2.6
30-130
40
35
TAL-M15-2.5-200
15
7
2.5
70-200
200
70
TAL-M16-2.6-10
16
8
2.6
30-105
35
10
TAL-M18-2.7-10
18
9
2.7
30-130
47
10
TAL-M18-3.2-30
18
9
3.2
30-130
48
30
TAL-M18-3.7-100
18
7
3.7
50-130
47
100
TAL-M20-2.95-10
20
9
2.95
30-130
55
10
TAL-M20-3.20-20
20
8
3.20
40-130
58
20
TAL-M22-3.15-10
22
9
3.15
30-130
58
10
TAL-M25-3.4-10
25
10
3.4
30-150
72
10
TAL-M25-3.5-250
25
10
3.5
80-280
90
250
TAL-25-3.6-20
25
9
3.6
40-150
71
20
TAL-M30-3.85-10
30
10
3.85
30-150
84
10
TAL-M35-4.5-25
35
10
4.5
40-180
130
25
Certifications
Installation

1) If extended height below 8m, the mast to be fixed with 3 layers nylon guy wires.

2)If the extended height between 8m-15m, the mast to be fixed with 3 layers pulling cord box .
3)If the extended height over 15m, the mast to be fixed with 4 layers pulling cord box.
